• Professional E27 Lamp Cap Gauge Lampholder Gauges E27-7006-21-5
قیمت مناسب Professional E27 Lamp Cap Gauge Lampholder Gauges E27-7006-21-5 آنلاین

Professional E27 Lamp Cap Gauge Lampholder Gauges E27-7006-21-5

جزئیات محصول:

محل منبع: چین dongguan
نام تجاری: kingpo
گواهی: iso9001
Model Number: 7006-21-5

پرداخت:

Minimum Order Quantity: 1
قیمت: To be quoted
جزئیات بسته بندی: جعبه ایمنی کارتن یا جعبه تخته سه لا
زمان تحویل: 7 روز
Payment Terms: T/T
قابلیت ارائه: 1000 عدد در ماه
اکنون تماس بگیرید

اطلاعات تکمیلی

نام تجاری: Kingpo Standard: IEC60061-3
HRC: C58 To C60 Material: Hardness Steel
برجسته:

Iec 60061 3,Go And Not Go Gauge

,

Go And Not Go Gauge

توضیحات محصول

E27 Lampholder gauges | Gauge for Testing Protection Against Bulb-Neck Damage And For Testing Contact- Making in Lampholder E27-7006-21-5





Purpose: to check:

a) protection against bulb-neck damage by the rim of the E27 lampholder.

b) contacting-making in E27 lampholders with respect to lamps having dimensions adverse to contact making.



Testing:

a) when the gauge is fully screwed home with a torque of

- 1.0Nm* for ceramic holders,

- 0.4Nm* for all other holders,

there shall be a clearance** between the gauge and the edge of the rim of the lampholder.

b) in this position, and with the lampholder connected with test circuit as show, the indicator lamp shall light.

* an increase of these value is under consideration.

** a feeler gauge with an approximate thickness of 0,08mm and a width of 5mm shall be used to check that this clearance exists over the full circumference.



Related gauges for E27 lamp holder:



E27 lamp holder gauge "GO" GAUGE FOR LAMPHOLDERS E27 7006-25A-2
NOT GO”GAUGE FOR SCREW THREADS OF LAMPHOLDERS E27 7006-26-4
GAUGE FOR TESTING PROTECTION AGAINST BULB-NECK DAMAGE AND FOR TESTING CONTACT-MAKING IN LAMPHOLDERS E27 7006-21-5
GAUGE FOR TESTING CONTACT-MAKING AND PROTECTION AGAINST ACCIDENTAL CONTACT DURING INSERTION OF LAMPS IN LAMPHOLDERS E27 7006-22A-5
GAUGE FOR DETECTING SIDE-CONTACTS WITH CUTTING-EDGES IN LAMPHOLDERS E27 7006-22B-1
GAUGE I FOR CHECKING SIDE-CONTACT RESILIENCY IN LAMPHOLDERS E27 7006-22C-1
GAUGE II FOR CHECKING SIDE-CONTACT RESILIENCY IN LAMPHOLDERS E27 7006-22D-1
